100mm Poly Ci Wheel 330Kg Capacity Castor (S447B)

The S447B from Richmond is a swivel frame castor and has a polyurethane tyred cast iron wheel. This swivel castor is in our heavy duty welded series range and can hold loads up to 330kg. The S447B wheel is fitted with ball bearings. The swivel frame of this castor allows full swivel rotation to enable steering. The polyurethane tyred cast iron wheel diameter is 100mm, the wheel width is 38mm and you can order separately (Part Number: PU449).

View Specifications View Specifications Shipping Information

Description
Specifications

Description

Precision built for durability under extreme working conditions, the Heavy Duty Welded Series is ideal for the exhaustive demands of industrial environments when a low profile high load bearing castor is required. Featuring a precision machined swivel ball race provides an unrivalled ultra smooth swivel action and a king pin made of high tensile steel to withstand high side impact loads. Finished in an attractive zinc plating to provide corrosion resistance, Richmond can also supply the heavy duty welded series in stainless steel for sue in high corrosive environments.

Product Code	S447B
Wheel Diameter (mm)	100
Frame Type	Swivel with Brake
Wheel Width (mm)	38
Wheel Type	Polyurethane Tyred Cast Iron Centred
Wheel Code	PU449
Wheel Bearing Type	Ball Bearing
Castor Height (mm)	132
Swivel Radius (mm)	90
Maximum Load Capacity (kg)	330
Recommended Load Capacity (kg)	250
Barcode / GTIN
