125mm Nylon Wheel 330Kg Capacity Castor (R502NY)

The R502NY from Richmond Rolling Solutions is a rigid frame castor and features a nylon wheel. This rigid castor is one of our heavy duty welded series range and can hold loads up to 330kg. The R502NY wheel is fitted with Stainless Steel Sleeve Bearings. The rigid frame design of this castor only allows linear movement unless used with swivel castors. The diameter of the nylon wheel is 125mm, the wheel width is 35mm and you can order separately (Part Number: NY501).

View Specifications View Specifications Shipping Information

Description
Specifications

Description

Precision built for durability under extreme working conditions, the Heavy Duty Welded Series is ideal for the exhaustive demands of industrial environments when a low profile high load bearing castor is required. Featuring a precision machined swivel ball race provides an unrivalled ultra smooth swivel action and a king pin made of high tensile steel to withstand high side impact loads. Finished in an attractive zinc plating to provide corrosion resistance, Richmond can also supply the heavy duty welded series in stainless steel for sue in high corrosive environments.

Product Code	R502NY
Wheel Diameter (mm)	125
Frame Type	Rigid
Wheel Width (mm)	35
Wheel Type	Nylon
Wheel Code	NY501
Wheel Bearing Type	Stainless Steel Sleeve
Castor Height (mm)	159
Swivel Radius (mm)	102
Maximum Load Capacity (kg)	330
Recommended Load Capacity (kg)	250
Barcode / GTIN
