150mm Cast Iron Wheel 500kg Capacity Castor (S6650)

300kg load capacity
Cast iron wheel
Suitable for extreme temperature ranges between -30°C-300°C
150mm diameter, 45mm width

This castors frame is a swivel frame which allows the castor to swivel or rotate 360° so the load may be steered.

View Specifications View Specifications Shipping Information

Specifications
Downloads

Product Code	S6650
Wheel Diameter (mm)	150
Frame Type	Swivel
Wheel Width (mm)	45
Wheel Type	Cast Iron
Wheel Code	Ci611
Wheel Bearing Type	Plain Bore
Castor Height (mm)	190
Swivel Radius (mm)	124
Maximum Load Capacity (kg)	500
Recommended Load Capacity (kg)	380
Temperature range (°C)	-30° to 300°

Download CAD Drawing (STEP file)	Download

-30˚ to 300˚C Wheel Temp

Swivel

Shipping Information

Flat rate shipping for all metropolitan and major regional locations where a Richmond Wheel & Castor warehouse is located.

Shipping will be calculated at checkout.

For more information on our freight charges, click & collect locations, and more
view our online shipping policy

*Not all items are available for purchase online.

Addon Components

Addons for your 150mm Cast Iron Wheel 500kg Capacity Castor (S6650). Click the product that you’re interested in for more info.

114 x 100mm Mounting Plate to suit Heavy Industrial Castors (BPR04)

(195BPHINRBAS)

135 x 110mm Mounting Plate M3 to suit Heavy Industrial Castors (BPR05)

(195BPINTRBASM3)
